Steel Coil Uncoiler Machine
fiber laser blanking system combines a fiber laser cutting machine with an automatic metal coil feeding system resulting in an efficient coil fed laser cutting solution .
Laser blanking reduces power consumption compared to its alternatives, such as press lines and results more efficient and flexible.
The automatic design of the whole process, which is from loading-uncoiling-leveling-cutting saves labor, realizes the net cutting of coil materials, and improves the utilization of sheet materials.
| Applicable materials | Cold Rolled Coil, Galvanized Coil, Stainless SteelCoil, Aluminum Coil |
| Working Area(mm) | 3000*1500/4000*2000/6000*1500mm |
| Laser power | 1kw/1.5kw/2kw/3kw/4kw |
| Material thickness | 0.5-2mm |
| Material width | 600-1500mm |
| Maximum coil weight | 10T |
| Maximum outer diameter of material | 1500mm |
| Material inner diameter | 508/610mm |
| Feeding accuracy | ±0.5mm |
| CNC System | Feeding Speed |
| Cutting Speed | 0-10M/min (stepless speed regulation) |
| Cooling Mode | Water Cooling |
| Control Software | Cypcut |
| Laser Head Brand | Raytools |
| Graphic Format Supported | AI, PLT,DXF,BMP, Dst |
| Weight | 3700KG |
——— END
Contact us for detailed information of Steel Coil Uncoiler Machine
What is Steel Coil Uncoiler Machine?
What is the cost of Steel Coil Uncoiler Machine?
What is the life span of Steel Coil Uncoiler Machine?
The customer who inquired
- Elizabeth Inquire 7 minutes ago
- James Inquire 23 hours ago
- Sarah Inquire 5 days ago
- Michael Inquire 13 days ago
- Emily Inquire 19 days ago
- William Inquire 26 days ago
- Amelia Inquire 17 days ago
- Benjamin Inquire 23 days ago
- Grace Inquire 13 days ago
- Logan Inquire 15 days ago
- Henry Inquire 28 days ago
- Mia Inquire 25 days ago
- Jackson Inquire 12 days ago
- Charlotte Inquire 10 days ago
- Lucas Inquire 5 days ago
- Amelia Inquire 18 days ago
- Aiden Inquire 11 days ago
- Harper Inquire 26 days ago
- Caden Inquire 24 days ago
- Evelyn Inquire 30 days ago
- Grayson Inquire 15 days ago
Previous：5-Axis Fiber laser cutting machine
Next：Not
Top Reviews
Related Products
Related Articles
-
The Economics of Automated Nesting in Custom Furniture: Machine Architecture, Throughput, and the Case of the Roctech Master SeriesCustom furniture manufacturing has shifted from batch production to high-mix, low-volume o...Feb 29 , 2024 -
Nesting CNC Automation in Panel Furniture: Market Structure, Machine Economics, and the Trajectory Toward Unmanned Cutting RoomsPanel furniture manufacturing has become the most aggressive adopter of nesting-based CNC ...Feb 29 , 2024 -
How Much Is a CNC Router? A Finding the Right Machine for Your BudgetInvesting in a CNC router can transform your manufacturing capabilities, but understanding...Feb 29 , 2024 -
Roctech Engineers' Suggestions on Maintenance of CNC Engraving MachinesThe maintenance of a CNC engraving machine is quick and straightforward. If carried out re...Feb 29 , 2024
Core Component Comparison — Steel Coil Uncoiler Machine
| Component | Brand / Specification |
|---|---|
| Laser Source | Raycus / IPG (fiber); Max optional |
| Laser Head | Raytools / WSX (auto-focus) |
| Servo Motor & Driver | Yaskawa (Japan) |
| Reducer | Shimpo / Apex |
| Controller / CNC System | CypCut / BoChu |
| Linear Guide | HIWIN / PMI (Taiwan) |
| Cooling System | Teyu / S&A industrial water chiller |
| Electrical Parts | Schneider / CHINT |
| Warranty | 2 Years (laser source 1-2 Years) |
* Typical industrial-grade configuration; final BOM is confirmed by order specification.
Frequently Asked Questions
Q1. What certifications does the Steel Coil Uncoiler Machine have?
The Steel Coil Uncoiler Machine is manufactured under a CE, ISO9001 and FDA certified quality system, ensuring compliance with international safety and quality standards.
Q2. What is the warranty and after-sales support?
We provide a 2-year warranty on core components, lifetime technical support, free remote diagnosis, and a guaranteed supply of original spare parts.
Q3. Can the Steel Coil Uncoiler Machine be customized to my production needs?
Yes. We offer OEM/ODM customization including working size, spindle or laser power, automatic tool changer, rotary axis, and full automation integration based on your material and throughput.
Q4. What is the lead time and shipping method?
Standard models are ready to ship in 15-25 working days. We arrange worldwide sea or air freight with reinforced export packaging and full documentation.
Q5. Do you provide installation and operator training?
Yes. We supply free remote installation guidance, step-by-step training videos, and on-site service is available upon request.
Q6. Are spare parts and consumables available?
Yes. We keep a long-term stock of original spare parts and common consumables and can dispatch them by express worldwide.
