CNC Router 1325-ATC
With Syntec Controller, Taiwan Hiwin Linear Rails, Yaskawa Servo Motor and Driver, Italian ATC spindle.
With auto positioning rods, can locate the materials automatic, save much time and improve the work efficiency.
Intelligent processing cross-border protection function can prevent the excessive processing caused by mechanical collision.
Furniture: doors, cabinets, tables and chairs.
Considering to the customers' different requirements about the sizes,we can provide: RC1530-ATC, RC2030-ATC, RC2040-ATC, RC2550-ATC etc.
Technical Parameter of CNC Router 1325-ATC
Parmeter | RC1325-ATC |
X,Y,Z,A,C Traveling | 1330*2500*220mm |
Table | Vacuum and T-slot Combined Table |
Frame | Welded Structure |
X,Y,Z Drive System | X,Y Helical rack and pinion,Z Ball screw |
Max Rapid Speed | 35000mm/min |
Max Working Speed | 20000mm/min |
Spindle Power | 9.0KW |
Spindle Speed | 0-24000RPM |
Driving System | Ysakawa Servo Motors |
Working Voltage | AC380v,50/60Hz，3Ph |
Command Language | G Code |
Operating System | Syntec Control |
Software | UG，PowerMill,Artcam,Type 3 |
Gross Weight | 3150KG |
Options | Vacuum pump |
——— END
Contact us for detailed information of CNC Router 1325-ATC
What is CNC Router 1325-ATC?
What is the cost of CNC Router 1325-ATC?
What is the life span of CNC Router 1325-ATC?
The customer who inquired
- Elizabeth Inquire 15 minutes ago
- James Inquire 21 hours ago
- Sarah Inquire 28 days ago
- Michael Inquire 16 days ago
- Emily Inquire 15 days ago
- William Inquire 29 days ago
- Amelia Inquire 25 days ago
- Benjamin Inquire 26 days ago
- Grace Inquire 30 days ago
- Logan Inquire 14 days ago
- Henry Inquire 27 days ago
- Mia Inquire 15 days ago
- Jackson Inquire 14 days ago
- Charlotte Inquire 8 days ago
- Lucas Inquire 22 days ago
- Amelia Inquire 7 days ago
- Aiden Inquire 22 days ago
- Harper Inquire 2 days ago
- Caden Inquire 21 days ago
- Evelyn Inquire 23 days ago
- Grayson Inquire 18 days ago
Previous：CNC Router 1530-ATC
Top Reviews
Related Articles
-
The Quiet Transformation of Woodworking CNC: From Standalone Routers to Integrated Nesting CellsAbstract—The woodworking CNC router, long regarded as a commodity machine category, is und...Aug 01 , 2024 -
Automated Nesting and Five-Axis Machining in Panel Furniture Production: Technology Adoption, Equipment Parameters, and the Rise of Integrated CNC WorkflowsAbstractThe panel furniture sector has shifted, over roughly the past decade, from stand-a...Aug 01 , 2024 -
From Three Axes to Five: The Quiet Restructuring of Woodworking CNC Machining CentersAbstract — The woodworking and panel-furniture machinery sector has, over the past decade,...Aug 01 , 2024 -
Automated Nesting and Five-Axis Machining: How CNC Equipment Makers Are Reshaping Panel Furniture and Complex-Curve ProductionAbstractThe economics of modern furniture and fabrication work increasingly hinge on how m...Aug 01 , 2024
Core Component Comparison — CNC Router 1325-ATC
| Component | Brand / Specification |
|---|---|
| Spindle | Italian HSD 9.0kW (air-cooled / ATC optional) |
| Servo Motor & Driver | Yaskawa (Japan) |
| Reducer | Shimpo / Apex |
| Controller / CNC System | Taiwan Syntec / LNC |
| Linear Guide | HIWIN / PMI (Taiwan) |
| Inverter (VFD) | Delta (Taiwan) |
| Rack & Pinion | APEX / HERION (Germany) |
| Electrical Parts | Schneider / CHINT |
| Warranty | 2 Years on core parts |
* Typical industrial-grade configuration; final BOM is confirmed by order specification.
Frequently Asked Questions
Q1. What certifications does the CNC Router 1325-ATC have?
The CNC Router 1325-ATC is manufactured under a CE, ISO9001 and FDA certified quality system, ensuring compliance with international safety and quality standards.
Q2. What is the warranty and after-sales support?
We provide a 2-year warranty on core components, lifetime technical support, free remote diagnosis, and a guaranteed supply of original spare parts.
Q3. Can the CNC Router 1325-ATC be customized to my production needs?
Yes. We offer OEM/ODM customization including working size, spindle or laser power, automatic tool changer, rotary axis, and full automation integration based on your material and throughput.
Q4. What is the lead time and shipping method?
Standard models are ready to ship in 15-25 working days. We arrange worldwide sea or air freight with reinforced export packaging and full documentation.
Q5. Do you provide installation and operator training?
Yes. We supply free remote installation guidance, step-by-step training videos, and on-site service is available upon request.
Q6. Are spare parts and consumables available?
Yes. We keep a long-term stock of original spare parts and common consumables and can dispatch them by express worldwide.
